We offer thyristor diode module MFC series in the power range of 25A up to 1000A and 800V up to 2400V. All the power modules use industry standard housings which are very low losses even in high operating temperature conditions.
| Device Type | MFC |
|---|---|
| Design | dual component |
| Configuration | Thyristor / Diode |
| Ordering Code | Device Type*Current *Voltage/100, Eg. MFC300-16 |
Key Features:
Parameters:
| Product | VRRM / VDRM [V] | IT(AV) / IF(AV) [A] @TC 85℃ | ITSM / IFSM [A] | Tjm [℃] | Outline |
|---|---|---|---|---|---|
| MFC25 | 800-1600 | 25 | 550 | 125 | |
| MFC55 | 800-1600 | 55 | 1300 | 125 | |
| MFC70 | 800-1600 | 70 | 1600 | 125 | |
| MFC90 | 800-1600 | 90 | 2000 | 125 | |
| MFC110 | 800-1600 | 110 | 2400 | 125 | |
| MFC135 | 800-1600 | 135 | 3600 | 125 | |
| MFC160 | 800-1600 | 160 | 5400 | 125 | |
| MFC200 | 800-1600 | 200 | 7200 | 125 | |
| MFC250 | 800-1600 | 250 | 8500 | 125 | |
| MFC300 | 800-1600 | 300 | 9300 | 125 | |
| MFC400 | 800-1600 | 400 | 12000 | 125 | |
| MFC500 | 800-1600 | 500 | 14500 | 125 | |
| MFC600 | 800-1600 | 600 | 13000 | 125 | |
| MFC800 | 800-1600 | 800 | 16000 | 125 | |
| MFC1000 | 800-1600 | 1000 | 20000 | 125 |
Notes: Voltage > 1800V is also available, please contact with us if you need.
